Features
- Available in both Radial & Mixed Flow options
- Delivery Sizes commensurate with Flow
- Maximum Outer Diameter is 96 mm, in cases of Jotter Pumps, OD = 99 mm
- Motors are in Water-filled & Oil-filled applications.
- Motor Power ranges from 0.50 HP through 7.50 HP
- Oil-filled Motors are available in 1 Phase, 1.00 HP only
- Motors of capacity 0.50 HP through 5.00 HP are available in 1 Phase
- Motors of capacity 1.00 HP through 7.50 HP are available in 3 Phase
- Coupling is over self-aligning spline arrangement
- Thrust Bearing is made up of Carbon
Nomenclature
E.g.,
| A4S | S/P | 0100 | V4 | 004 | 10 |
 |
|
|
|
|
|
| Stages | |||||
| Hydraulic Name | |||||
| V4 Denotes 4" Pump (Water-filled) VO Denotes 4" Pump (Oil-filled) |
|||||
| Motor Power 0100 denotes 1.00 HP 0050 denotes 0.50 HP 0500 denotes 5.00 HP, etc |
|||||
| Phase S/P Denotes 1 Phase T/P Denotes 3 Phase |
|||||
| General Prefix A4S Denotes Water-filled 4" Motors AOS Denotes Oil-filled 4" Motors |
|||||
MOC
| Part | Material | Grade | Reference Std |
|---|---|---|---|
| Shaft | Chrome Steel | AISI 410 | ASTM A 276 |
| Shaft* | Chrome Steel | AISI 431 | ASTM A 276 |
| Impeller | NORYL | 20% Glass Filled | - |
| Diffuser/Bowl | NORYL | 20% Glass Filled | - |
| NRV Body | Cast Iron | FG 200 | IS: 210 |
| Bushes | Bronze | LTB 4 | IS: 318 |
| Rotor | Copper | - | - |
| Rotor | Aluminium** | - | - |
Motors
| Ø | OD | Rated Power | Rated Current | Operating Voltage | |
|---|---|---|---|---|---|
| in mm | in kW | in HP | in Amperes | in Volts | |
| One | 96 | 0.37 | 0.50 | 5.30 | 160-240 |
| One | 96 | 0.55 | 0.75 | 6.20 | 160-240 |
| One | 96 | 0.75 | 1.00 | 7.50 | 160-240 |
| One (OF) | 96 | 0.75 | 1.00 | 7.00 | 120-220 |
| One | 96 | 1.10 | 1.50 | 10.50 | 160-240 |
| One | 96 | 1.50 | 2.00 | 13.80 | 160-240 |
| One | 96 | 2.20 | 3.00 | 19.80 | 160-240 |
| One | 96 | 3.70 | 5.00 | 25.00 | 160-240 |
| Three | 96 | 0.75 | 1.00 | 3.50 | 300-440 |
| Three | 96 | 1.10 | 1.50 | 4.00 | 300-440 |
| Three | 96 | 1.50 | 2.00 | 4.80 | 300-440 |
| Three | 96 | 2.20 | 3.00 | 6.90 | 300-440 |
| Three | 96 | 3.70 | 5.00 | 10.60 | 300-440 |
| Three | 96 | 4.50 | 6.00 | 12.60 | 300-440 |
| Three | 96 | 5.50 | 7.50 | 15.50 | 300-440 |
Pumps
| Hydraulic Name | Hydraulic | Discharge at BEP | Head/Stage at BEP | NRV Size | Pump OD | Motor OD | Max.No. Of Stages |
|---|---|---|---|---|---|---|---|
| - | - | LPM | M | mm | mm | mm | - |
| 100001 | Radial | 30 | 4.00 | 32 | 96 | 96 | 50 |
| 100002 | Radial | 39 | 3.48 | 32 | 96 | 96 | 55 |
| 100004 | Radial | 60 | 4.80 | 32 | 96 | 96 | 40 |
| 100005 | Radial | 102 | 4.00 | 38 | 96 | 96 | 30 |
| 100007 | Radial | 118 | 4.00 | 40 | 96 | 96 | 18 |
| 100010 | Radial | 132 | 4.00 | 50 | 96 | 96 | 25 |
| 100012 | Radial | 144 | 4.25 | 50 | 96 | 96 | 20 |
| 100030 | Mixed | 252 | 3.31 | 50 | 96 | 96 | 16 |
| 100018 | Mixed | 288 | 3.17 | 65 | 96 | 96 | 15 |
| 100-H1 | Radial | 30 | 4.84 | 32 | 96 | 96 | 65 |
| 100-H2 | Radial | 45 | 5.11 | 32 | 96 | 96 | 60 |
| 100-H3 | Radial | 60 | 5.00 | 32 | 96 | 96 | 50 |
